Konnected Garage Door Relay

When the relay is closes it connects the two terminals from your garage door opener together which mimics a momentary button push to activate the opener.

Konnected garage door relay.

Power connect the 5v on the board to vcc on relay female to female jumper ground connect gnd next to 5v on the board to the g on the relay female to female control connect pin to in on relay repeat if using multiple relays wire warning buzzer optional but recommended you can use any zone for the buzzer except pin rx. The gd00z 4 garage door opener remote controller opens or closes a sectional garage door remotely through a z wave certified gateway or security panel. A konnected diy board wifi module. Installers only need to pair the unit into the gateway mount the unit connect two wires.

Wired through konnected 12v power supply. You would take a wire out of the no side of the relay to the sprinkler valve. Trust me connect a wire to each of the terminals on the garage door that you identified on step 1. Basically you would take the hot side to the com on the relay switch side.

It is compatible with virtually any automatic garage door opener connected to a sectional garage door. If you want to use konnected to control a garage door opener sprinkler system or turn on off something that has a separate voltage source you use a relay module. Unplug the garage door it moving while you are on a ladder installing doesn t go well. It is a way to open or close a circuit in this case via a signal from the konnected microcontroller.

Out of the valve you would go back to the neg side of the supply to complete the circuit. Power trigger side of the relay. The model of my chamberlain opener does not activate by momentarily connecting the two terminals. The relay isolates the circuit on the device you want to control from the device that s controlling it.

A relay is a type of switch that can be controlled with an electrical signal. The relay isolates the circuit on the device you want to control from the device that s controlling it. Connect the other end of the wires to the contacts on relay. In your setup you are activating the garage door using a relay which momentarily closes.
